14SBTF end-coated narrow line wide semiconductor laser module
14SBTF tail-fibre containment module is a star product of the Apricot Wisdom NL narrow-width laser line; it is based on VBG lock wave technology; compatible with TEC sealing; achieves stable power output and high border depressive ratio; has good temperature wavelength drift; multiple wavelengths are optional
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Continuous output power | 100; 500; 600; 800mW |
| He's on the wavelength | ±0.5nm |
| spectral width | <0.1; <0.3nm |
| Wave length with temperature properties | 0.01nm/°C |
| Wave length with current properties | 0.05; 0.06nm/A |
| Heat-sensitive electrical resistance parameters | 10±1%/3930 |
| Maximum voltage | 6.3V |
| Fibre-pack diameter | 125μm |
| Fibre coating diameter | 250μm |
| Fibre length | 100±10 (customable)cm |
| Numerical aperture | 0.22 |
| Connector | FC/PC, SMA905 |
| Central wavelength | 532; 638; 785; 808; 830; 981; 1064nm |
| Border Model Impression Ratio | >35; >40dB |
| Microefficiency | 0.8; 0.7; 0.9W/A |
| Electricity | <2000μA |
