HQF series light pump long pulse 2940 nm Er:YAG laser
The HQF series of lamps pump a long pulse of 2940 nm Er; the YAG laser consists of a laser module, an energy detection module; the output wavelength of 2940 nm; the medium infrared laser of 2940 nm wavelength is at its strongest absorption peak in the hydroxyl phosphorus limestone OH- and water molecules; and thermal damage range is small. The product is characterized by high energy, high stability and even light. Wide application in biomedical fields; spare parts such as output fibre, light arm
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Wavelength | 2940nm |
| Single pulse energy | 500mJ@20Hz, 2000mJ@10Hz |
| Pulse width | 300~500 |
| Beam Mode | Tamo |
| Laser energy instability | Better than 20% |
| Laser energy recovery | Better than 20% |
| Indicator light wavelength | 532±20nm |
| Indicator light power | >2mW |
| Working conditions | Temperatures: 10°C ~ 30°C; relative humidity: 10% ~ 73% (non-condensed); atmospheric pressure: 86kPa ~ 106kPa; power demand: 220V/110V (1)(AC), 50/60Hz |
Applications
Key Features
Datasheet
Supplier Information
