MPM11 Series Dust Sensor
MPM11 Dust Sensor
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Diameter | 0.3~10μm |
| Output Method | UART / IIC / PWM |
| Operating Voltage | 4.5~5.5V, Voltage: 5V |
| Operating Current | ≤85mA |
| Current | ≤45μA |
| Detection principle | Laser scattering principle |
| Detection concentration range | 0~1000μg/m3 |
| Particulate matter mass concentration resolution | 1μg/m3 |
| single response time | ≤1s |
| Overall response time | ≤10s |
| Detection accuracy | ±10%(@100~500μg/m3)； ±10μg/m3(@ 0~100μg/m3) |
| Data interface level | L<0.8@3.3V H>2.7@3.3V |
| mean time between failures | ≥3 years |
| Storage environment | -30~70℃ |
Applications
