Center HT510A
Center; 2, BT30(BBT30*), 24000rpm
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Dimensions | 3-14125 mm |
| Positioning Accuracy | 0.005 mm |
| Dimensions | 168023202260 mm |
| Equipment Weight | 2400 kg |
| Shaft travel | 510/400/330 mm |
| Distance from spindle nose to worktable | 150-480 mm |
| Distance from spindle nose to worktable | 350-670 mm |
| Workbench clamping area | 650400 mm |
| Tool type | BT30 |
| Number of tool magazines | 21(30) Pockets |
| Tool magazine form | Front servo tool magazine |
| Tool changing time | 1.6 sec |
| Cutting speed | 30/30/30 m/min |
| Fast movement speed | 48/48/48 m/min |
| Output Power | max:19 Kw |
| Diameter | max:100/140 mm |
| Weight | max:3 Kg |
