MU9403 Multi-Channel Power

U9225C 24.5～29Gps Tunable 100G TOSA/ROSA Device, Device; U9225C High-Precision, Features, Application

Instrument Introduction: BCSP-Plane is a spectrum analyzer with automatic adjustment of the incident light angle, covering a wavelength range of 380-1100 nm. It can automatically measure the spectra of various flat optical components at any angle between 5-79 degrees in reflection and 0-85 degrees in transmission. Paired with newly developed automated measurement software, the instrument can continuously measure transmittance and reflectance at any number of different angles in a single run. In addition, polarized light and color measurements are supported. Product Features: 1. Fully automatic spectral data measurement - the sample rotation stage works in conjunction with the integrating sphere rotation stage to complete measurements automatically 2. Fully automatic multi-angle transmittance measurement - automatic spectral measurement at any angle between 0-85 degrees in transmission 3. Fully automatic multi-angle reflectance measurement - automatic spectral measurement at any angle between 5-79 degrees in reflection 4. Polarizer - diverse configurations. Customers can freely configure polarizers according to their needs to selectively transmit light vibrating in a given direction, eliminating or reducing strong reflections from non-metallic surfaces and thereby removing or reducing glare spots.

Instrument Description: The spherical transmittance spectrum analyzer is a full-wavelength absolute transmittance measurement instrument that quickly and accurately measures the relative and absolute transmittance of various spherical, aspherical, and other optical components, displaying real-time single-point and multi-point wavelength transmittance data as well as average transmittance data over specified wavebands. Features: ● Fast measurement, single measurement within 50 ms ● User-friendly measurement software with simple operation Instrument parameters:

Model Model#: GM8036

GM8036-II is equipped with PC-testing software;

Test measurements exclusive website: Mi.yokogawa.com/cn (Chinese) http://tmi.yokogawa.com (English) Specifications and characteristics: AQ6370D; AQ6373B; AQ6374; AQ6375B; AQ6376 Frequency wavelength range: Photocommunication 600; 350; photocommunication 350; 1200; 1500nm

The 6370 series is a high-speed high-performance spectroscopy analyser based on distillation raster technology. The range of wavelengths can be measured in the series; five types of machines can be covered from visible to medium-wave infrared (350 ~ 3400 nm); measurement needs for various R & D and industrial manufacturing applications are met
