TeraFlash smart
The TeraFlash smart is a time-domain terahertz platform designed for industrial applications, offering high-speed and precise measurements for thickness gauging and inline monitoring.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Laser Wavelength | 1560nm |
| Laser Pulse Width | typ.80fs |
| Laser Repetition Rate | 80MHz |
| External Fiber Length | 10.8m |
| Terahertz Emitter | PCA-TD-030-TX-1: InGaAs/InP photoconductive switch with 25μm strip-line antenna, 0.3m fiber pigtail |
| Terahertz Receiver | PCA-TD-030-RX-1: InGaAs/InP photoconductive switch with 25μm dipole antenna, 10μm gap, 0.3m fiber pigtail, integrated preamplifier |
| Antenna Package | Cylindrical, 25mm, integrated Si lens and SM/PM fiber pigtail |
| Scan Range | 150ps/300ps/700ps |
| Scan Speed | 1600traces/s(150ps), 800traces/s(300ps), 200traces/s(700ps) |
| Spectral Range | 0.1–4.5THz, in<1s |
| Average Terahertz Power | typ.30μW |
| Time-domain Dynamic Range | typ.>50dB in<1ms, 80dB in1s |
| Spectral Peak Dynamic Range | typ.35dB in<1ms, >60dB in1s |
| Usable Terahertz Path Length | 10–180cm, adjustable via software (electronic phase shift) |
| Frequency Resolution @ Max. Scan Range | <1.5GHz |
| Computer Interface | Ethernet and USB |
| Computer Interface | Data streaming via USB |
| Computer Software | LabView-based GUI, included |
| Size (H x W x D) | 200x450x440mm³ |
| System Weight | 20kg |
| Operating Voltage | 24VDC, power supply included |
| Accessories | Transmission optomechanics |
| Accessories | Reflection head |
