Electro-optic Modulator
The Electro-optic Modulator is a high-performance device designed for precise modulation of optical signals. It is widely used in various optical systems and applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Operating Wavelength Range | 400-700nm |
| Modulation Frequency | DC-10MHz |
| Insertion Loss | ≤2.0dB |
| Optical Damage Threshold | >500MW/cm² |
| Beam Deflection Angle | ±2° |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +80°C |
Applications
Key Features
Datasheet
