702915/702916 Current Probes
The 702915 and 702916 current probes are designed for precise measurement of standby current and ripple current in circuit designs, offering high sensitivity and wide measurement ranges.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Bandwidth 702915 | DC to 50MHz (-3dB) |
| Bandwidth 702916 | DC to 120MHz (-3dB) |
| Rise Time 702915 | ≤7ns |
| Rise Time 702916 | ≤2.9ns |
| Delay Time 702915 | 12ns (typical) |
| Delay Time 702916 | 12ns (typical) |
| Maximum Current Connection | 30Arms |
| Range 30A | 30Arms |
| Range 5A | 5Arms |
| Range 0.5A | 0.5Arms |
| Output Voltage Sensitivity 30A | 0.1V/A |
| Output Voltage Sensitivity 5A | 1V/A |
| Output Voltage Sensitivity 0.5A | 10V/A |
| Maximum Allowable Current 30A | ±30Apeak (<10MHz), ±0.3Apeak (<10MHz) |
| Maximum Allowable Current 5A | ±5Apeak |
| Maximum Allowable Current 0.5A | ±0.75Apeak (<10MHz), ±0.3Apeak (<10MHz) |
| Operating Temperature Range | -40°C to +85°C, 80% RH |
| Storage Temperature Range | -40°C to +80°C, 80% RH |
| Power Supply Voltage | ±12V to ±15V |
| Power Supply Current | ≤75mA rms, 60μArms (typical) |
| Weight | Approx. 370g |
