702915/702916 Current Probes
The 702915 and 702916 current probes are designed for precise measurement of standby and ripple currents in circuit designs, offering high sensitivity and wide bandwidth capabilities.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Bandwidth 702915 | DC to 50MHz (-3dB) |
| Bandwidth 702916 | DC to 120MHz (-3dB) |
| Rise Time 702915 | ≤7ns |
| Rise Time 702916 | ≤2.9ns |
| Delay Time 702915 | 12ns (typical) |
| Delay Time 702916 | 12ns (typical) |
| Maximum Connection Current 702915 | 30Arms |
| Maximum Connection Current 702916 | 30Arms |
| Measurement Current Range 702915 | 0 to ±30Apeak, 0 to ±5Apeak, 0 to ±0.5Apeak |
| Measurement Current Range 702916 | 0 to ±30Apeak, 0 to ±5Apeak, 0 to ±0.5Apeak |
| Output Voltage Ratio 702915 | 0.1V/A, 1V/A, 10V/A |
| Output Voltage Ratio 702916 | 0.1V/A, 1V/A, 10V/A |
| Accuracy 702915 | ±3.0% rdg ±1mV, ±1.0% rdg ±1mV (10mA to 10A range) |
| Accuracy 702916 | ±3.0% rdg ±1mV, ±1.0% rdg ±1mV (10mA to 10A range) |
| Maximum Allowable Current 702915 | ±50Apeak (<10MHz), ±0.75Apeak (<10MHz), ±0.3Apeak (<10MHz) |
| Maximum Allowable Current 702916 | ±50Apeak (<10MHz), ±0.75Apeak (<10MHz), ±0.3Apeak (<10MHz) |
| Noise 702915 | ≤75μVrms, 60μArms (typical) |
| Noise 702916 | ≤75μVrms, 60μArms (typical) |
| Operating Temperature Range 702915 | -40°C to +40°C, ≤80% RH |
| Operating Temperature Range 702916 | -40°C to +40°C, ≤80% RH |
| Storage Temperature Range 702915 | -40°C to +70°C |
| Storage Temperature Range 702916 | -40°C to +70°C |
| Power Supply Voltage Range 702915 | ±12V to ±15V |
| Power Supply Voltage Range 702916 | ±12V to ±15V |
| Weight 702915 | Approx. 370g |
| Weight 702916 | Approx. 370g |
