702915/702916 Current Probes
The 702915 and 702916 current probes are designed for precise measurement of standby current and ripple current in circuits, offering high sensitivity and wide bandwidth capabilities.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Bandwidth | DC to 50MHz (-3dB) (702915), DC to 120MHz (-3dB) (702916) |
| Rise Time | ≤7ns (702915), ≤2.9ns (702916) |
| Delay Time | 12ns (typical) |
| Maximum Current | 30Arms |
| Measurement Range | 30A, 5A, 0.5A |
| Output Voltage Ratio | 0.5A range: 10V/A, 5A range: 1V/A, 30A range: 0.1V/A |
| Maximum Peak Current | ±50Apeak (<DC to 10MHz), ±0.75Apeak (<10MHz), ±0.3Apeak (<10MHz) |
| Operating Temperature Range | 0°C to +40°C, 20% to 80% RH (no condensation) |
| Storage Temperature Range | -20°C to +60°C, 20% to 80% RH (no condensation) |
| Power Supply Voltage | ±12V to ±15V |
| Weight | Approx. 370g |
