702915/702916 Current Probes
The 702915 and 702916 current probes are designed for precise measurement of standby current and ripple current in circuit designs, offering high sensitivity and wide bandwidth.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Frequency Range 702915 | DC to 50MHz (-3dB) |
| Frequency Range 702916 | DC to 120MHz (-3dB) |
| Rise Time 702915 | ≤7ns |
| Rise Time 702916 | ≤2.9ns |
| Delay Time 702915 | 12ns (typical) |
| Delay Time 702916 | 12ns (typical) |
| Maximum Current 702915 | 30Arms |
| Maximum Current 702916 | 30Arms |
| 0.5A Range | 0.5Arms |
| 5A Range | 5Arms |
| 30A Range | 30Arms |
| Output Voltage Sensitivity 0.5A Range | 1V/A |
| Output Voltage Sensitivity 5A Range | 0.1V/A |
| Output Voltage Sensitivity 30A Range | 0.01V/A |
| Maximum Peak Current 0.5A Range | ±0.75Apeak (10MHz), ±0.3Apeak (10MHz) |
| Maximum Peak Current 5A Range | ±7.5Apeak |
| Maximum Peak Current 30A Range | ±50Apeak |
| Operating Temperature Range | -40°C to +85°C, 80% RH |
| Storage Temperature Range | -40°C to +80°C, 80% RH |
| Power Supply Voltage | ±12V to ±15V |
| Power Supply Current | ≤75mA rms, 60μArms (typical) |
| Weight | Approx. 370g |
