PLM-100 Polarization Dependent Loss Meter
The PLM-100 is a high-precision polarization dependent loss meter designed for stable and accurate PDL, ER, and IL measurements. It features improved source isolation, electronics, optics, and continuous laser power feedback, ensuring repeatable and stable measurements.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Fiber Type | SMF-28 (9/125) |
| Wavelength Range (nm) | 1260-1650 |
| Detector Type | InGaAs |
| Power Range (dBm) | 5 to -65 |
| PDL Accuracy (dB) | ±0.005 (0.3% of PDL) |
| PDL Calculation Method | Mueller Matrix |
| PDL Dynamic Range (dB) | 0 to 0.3 |
| Relative Power Accuracy (dB) | ±0.05 |
| PDL Measurement Time (s) | 1 |
| Remote Interface | Ethernet/USB |
| Input Voltage | 100-240V AC, 50-60Hz |
| Power Consumption (VA) | 80 maximum |
| Display | Ethernet/USB |
| Unit Dimension W×H×D (cm) | 36×13×34 |
| Shipping Box Dimensions W×H×D (cm) | 49×25×49 |
| Total Shipment Weight (g) | 9200 |
| Operating Temperature (°C) | 10 to 40 |
| Storage Temperature (°C) | Maximum 95% RH from 10 to 40 |
