OTF-930
The OTF-930 is a polarization-independent 80 nm tunable filter featuring Santec's unique 'Linear Sliding' technology. This innovation enables precise and continuous wavelength tuning with consistent optical properties such as PDL, bandwidth, and insertion loss. Designed for cascading filters to increase isolation with minimal insertion loss, the OTF-930 is suitable for most fiber optic applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Tuning Range | 1530-1610nm, 1500-1630nm (25 bandwidth), 1270-1350nm (10 bandwidth) |
| Resolution | 0.01nm |
| Accuracy | <±0.1,<±0.15(<±0.25) |
| Repeatability | <±0.01,<±0.025(<±0.05) |
| Temperature Stability | <±0.005,<±0.025(<±0.15) |
| PDL (SMF) | <0.2dB |
| Insertion Loss | ≤4.5dB |
| Relative Accuracy | <±0.1dB |
| Max Input Power | +20dBm |
| PMD | <0.1ps |
| Operating Temperature | 0-40°C |
| Storage Temperature | -20-80°C |
| Fiber Type | SMF or PMF |
| Optical Connector | FC or SC |
| Connector Polish | SPC or APC |
| Interface | GPIB (IEEE-488) & RS-232C |
| Voltage | AC100-240V |
| Frequency | 50-60Hz |
| Power Consumption | 35W@230V, 20W@120V |
| Dimensions (W×H×D) | 210×80×300mm |
| Weight | 4kg |
Applications
Key Features
Datasheet
