Tapered Amplifiers
Tapered amplifiers (TA) are designed with a flared geometry to maintain a single transverse mode while boosting power to the watt level. They are typically used in master oscillator power amplifier (MOPA) configurations and feature high-quality AR coatings.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Wavelength Range (nm) | 633-1550 |
| WLmin (nm) | 632-1232 |
| WLmax (nm) | 636-1590 |
| Maximum Power (mW) | 1200-7000 |
| Maximum Current (mA) | 1500-7000 |
| Article Number | TA-0633-0100-1 to TA-1550-1000-1 |
| Stock | u.r. to >3 |
| Remark | System only, limited lifetime, no warranty; ASE outside specified ranges; Please inquire for wider tuning possibilities |
