Cube Beamsplitter
Cube Beamsplitters are optical components designed to split a beam of light into two separate beams. They are widely used in laser systems, imaging systems, and optical testing setups.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Dimension | 5mm, 10mm, 20mm |
| Wavelength Range | 550-750nm |
| Transmission | ≥90% |
| Reflection | ≥90% |
| Splitting Ratio | 50:50 ±5% |
| Surface Quality | 40/20 |
| Optical Material | BK7, UV Fused Silica |
| Coating Type | Dielectric Coating |
Applications
Key Features
Datasheet
