FOT-600 Optical Loss Test Set (OLTS)
The FOT-600 combines singlemode light source and power meter capabilities in a compact and rugged design. It is ideal for automated link qualification, featuring a memory capacity of 1000 data items and USB data transfer.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Detector | GeX |
| Power Range (dBm) | 26 to -55 |
| Wavelength Range (nm) | 800 to 1650 |
| Calibrated Wavelengths (nm) | 800,820,830,840,850,860,870,880,910,980,1060,1270,1280,1290,1300,1310,1320,1330,1340,1370,1390,1450,1460,1470,1480,1490,1500,1510,1520,1530,1540,1550,1560,1570,1580,1590,1600,1610,1620,1630,1640,1650 |
| Power Uncertainty | ±5% ±3nW |
| Resolution (dB) | ±0.01 (2dBm to -45dBm) |
| Automatic Offset Nulling | Yes |
| Display Units | dB |
| Display Units | dBm |
| Display Units | W |
| Tone Generation and Detection | 270Hz, 1kHz, 2kHz |
| Auto-Switching | Yes |
| Data Storage (items) | >=1000 |
| Battery Life (hours) | 72 (power meter mode), 50 (source or OLTS in auto mode) |
| Central Wavelength (nm) | 1310±20, 1550±20 |
| Spectral Width (nm) | ≤5 |
| Output Power (dBm) | 3 |
| Power Stability (dB) | 15min ±0.03, 8h ±0.1 |
| Automatic Wavelength Switching | Yes |
| Recommended Calibration Period (years) | 3 |
| Warranty (year) | 1 |
| Size (HxWxD) | 190mm x 100mm x 62mm |
| Weight | 0.48kg |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 0% to 95% non-condensing |
| Emitter type | Laser |
| Wavelength (nm) | 650 |
