MY3308 Handheld Insertion Loss Tester
MY3308 is designed for testing optical return loss and insertion loss in fiber optic systems. It provides precise measurements for various fiber optic components, ensuring optimal performance and reliability.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Test Wavelength (nm) | 1310/1550(±20) |
| Spectral Width (nm) | <5nm |
| Output Power (dBm) | ≥-5dBm |
| Stability (8 hours) (dB) | ±0.05dB |
| Measurement Range (dB) | 0~70dB |
| Resolution (dB) | 0.01dB |
| Wavelength Range (nm) | 800~1700nm |
| Display Unit | dBm |
| Display Unit | dB |
| Display Unit | mW |
| Measurement Range (dBm) | -70~+6dBm |
| Cable Length (m) | 1000m |
| Power Supply | 3x1.5V AA batteries/USB power |
| Operating Temperature (°C) | +5~+40°C |
| Storage Temperature (°C) | -15~+70°C |
| Relative Humidity (%) | 0~85 (non-condensing) |
| Weight (g) | 380g |
| Dimensions (mm) | 180x90x36.5 |
