Plastic Optical Fiber Patch Cables

Plastic Optical Fiber Patch Cables

Supplier
Fibretop
Part Number
Plastic Optical Fiber Patch Cables
Category
Fiber Optics
Origin
China

Plastic optical fibers are used as transmission media in industrial control environments with severe electromagnetic interference and high signal requirements. POF can be applied to RS232, RS422, 100Mbps Ethernet, and other standard interfaces. It ensures stable and reliable communication, high-speed transmission of industrial control signals and commands, and avoids the risk of communication failure caused by electromagnetic interference.

Specification Snapshot
Fiber Diameter(mm)
1.0
Cable Diameter(mm)
2.2±0.1
Connector Loss(dB)
<0.5
Application Wavelength(nm)
650
Bandwidth(MHz·100m)
≥10
Request a Quote Download Datasheet Chat
Save to Favorites Save to Favorites

Overview

Plastic optical fibers are used as transmission media in industrial control environments with severe electromagnetic interference and high signal requirements. POF can be applied to RS232, RS422, 100Mbps Ethernet, and other standard interfaces. It ensures stable and reliable communication, high-speed transmission of industrial control signals and commands, and avoids the risk of communication failure caused by electromagnetic interference.

Specifications

ParameterValue
Fiber Diameter(mm)1.0
Cable Diameter(mm)2.2±0.1
Fiber MaterialPMMA (Polymethyl Methacrylate)
Jacket MaterialPolyethylene
Fiber Attenuation(dB/m)≤0.2
Connector Loss(dB)<0.5
Numerical aperture0.5
Application Wavelength(nm)650
Incident Angle≤60°
Bandwidth(MHz·100m)≥10
Cable Length(m)1~100 customizable
Bending Radius≥10 times fiber diameter
Operating Temperature(°C)-40~+85
Storage Temperature(°C)-40~+85
Refractive Index ChangeStep Index

Applications

1. Industrial automation control systems 2. Industrial robots and short-distance systems and service systems 3. Communication systems 4. Multimedia systems 5. Medical systems 6. Power systems

Key Features

1. Anti-electromagnetic interference, reliable signal transmission 2. Easy to install and maintain 3. Lightweight and safe 4. High flexibility 5. High temperature and low temperature resistance (-40 to 85°C)

Datasheet

Product Datasheet
PDF
Download
