1550nm Polarization Maintaining Module
The polarization maintaining module is a high-performance optical component designed for fiber communication and sensing systems. It adopts a wave plate structure to ensure stability during the combination process, making it suitable for vibration-sensitive applications. This product is easy to integrate into systems and offers multiple configurations to meet diverse application needs.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Center Wavelength (nm) | 1550nm |
| Operating Wavelength Range (nm) | 1524~1572nm |
| Port Type | 1x4 |
| Maximum Insertion Loss at 23℃ (dB) | 8.1dB |
| Maximum Wavelength Uniformity (dB) | 0.6dB |
| Uniformity (dB) | 0.6dB |
| Minimum Extinction Ratio at 23℃ (dB) | Dual-axis operation: 18, Fast-axis blocked: 22dB |
| Minimum Return Loss (dB) | 50dB |
| Maximum Insertion Thermal Stability (dB) | 0.5dB |
| Maximum Optical Power (mW) | 500mW |
| Maximum Tensile Strength (N) | 5N |
