EB-FCP-175-200-0888-0.5-V
High-power fiber-coupled laser module with a center wavelength of 888nm, designed for solid-state laser pumping applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Center Wavelength@lop | 888nm |
| Wavelength Tolerance | ±0.5nm |
| Output Power | 175W |
| Spectral Width (FWHM) | 0.3nm |
| Numerical aperture | 0.22 |
| Fiber Core | 200/400μm |
| Fiber Connector | SMA905 |
| Fiber Length | 1.2m |
| Power Conversion Efficiency | 52% |
| Threshold Current | 1.4A |
| Operating Current | 13A |
| Operating Voltage | 28.5V |
| Operating Temperature | 0-50°C |
| Storage Temperature | -40-80°C |
| Wavelength Temperature Coefficient | 0.01nm/°C |
| Anti Reflection Wavelength Range | 1030-1200nm |
| Reflection Efficiency | ＞30dB |
| Soldering Temperature | 260°C(10sec) |
