1000BASE SFP SR(850nm 550M) OSFP-108505
This enhanced SFP transceiver includes DDM and meets Ethernet requirements for 1.25Gbps communications. Alarms/warnings follow SFF-8472 MSA version 10.4 through I2C. It supports 1.25G at 850nm over up to 550m of multimode fiber. Subwatt consumption and excellent EMI enable dense ports. RoHS compliance and industry safety design/testing include Class I laser conformity with US FDA/CDRH and IEC-60825. The SFP SR connects to a standard 20-contact SFP connector for hot swapping, allowing maintenance/configuration without host power removal. Transmit/receive DATA interfaces are internally AC-coupled. LV-TTL transmitter-disable input and LOS output are provided. A pull-ring latch enables easy release and meets SFP MSA. A +3.3V supply supports case temperatures 0°C to +70°C commercial or -40°C to +85°C industrial. A metal housing shields EMI.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Emission wavelength | 850nm |
| Specification | 550m |
Key Features
Datasheet
Please provide your email to download the datasheet.
Invalid email format. Please try again.
