Semiconductor Laser Processing System DLS-01 Series

Overall dimensions: L1600mmx W1200mm x H1800mm Working Surface Height [±50mm]: 950mm±50mm Chart Dimensions: 800mmx1200mm

Huaya's intrinsic-parameter calibration equipment was among the first domestically mass-produced systems and has been recognized by several leading automotive camera module manufacturers. As ADAS adoption increases, this equipment has become essential to ADAS camera manufacturing. It calibrates and tests COD/PP/EFL (focal length ratio), radial distortion K1-K6 and tangential distortion P1-P2.

Voltage: 220v16A Gas pressure: 0.4~0.7Mpa Industrial computer: IPC+Win7

Huaya Intelligent's dual-track AA equipment is one of its most mature and representative products, developed for AD AS cameras and ultrahigh-definition 800W camera modules. Traditional AA equipment uses either the Sensor or Lens as a reference and aligns the other while maintaining equipment precision. Previous processes can cause the reference part to differ substantially from the system optical axis. Higher pixel counts, especially the longer EFL of ADAS cameras, make differences between theoretical and actual axes more critical. The dual-adjustment-stage system uses high-precision coordinated adjustment to establish the optimum Sensor plane and correct the Lens for best image sharpness and optical axis. Parallel dual tracks improve both alignment precision and speed, with particular advantages for automotive ADAS modules.

Equipment - Voltage: 220V16A Equipment-Air Pressure: 0.4~0.7Mpa Equipment-Industrial Computer: IPC+Win7

Fully automatic active-alignment equipment adjusts the lens and CMOS units of camera modules. It includes automatic transport, information entry, dispensing, active focus and Uv curing. A nanometer-precision six-axis stage holds the lens group; precision optics and algorithms optimize MTF and fix the optimum position to complete AA focusing. Features: Broad applicability with compatible optical-path designs for different products. Modular construction and reserved mechanical and standard SMEMA electrical interfaces support upgrades. Fully enclosed process design meets production cleanliness requirements. MES compatibility stores traceable production information as .CSV files readable in Excel. Optional automatic loading/unloading carts and In Line production enable unattended automation.

I. Features: 1. Cleaves fibers with cladding diameters from 125μm to 600μm. 2. A sharp, durable American diamond blade is easy to replace/adjust. Each point makes over 3000 cleaves under normal use, depending on cladding material; theoretically 10 positions per blade are available. 3. Tension-and-scribe cleaving produces flat, low-angle faces, averaging <0.5°. Imported motors and precision guides control tension to 0.01kgf for repeatable, consistent cleaves. 4. Removable fiber holders provide accurate location/clamping, with matching holders for different core diameters and easy replacement. 5. A handheld 3.5-inch HD touchscreen editor clearly displays an intuitive interface for editing/storing TFC-600 parameters and selecting stored programs for different fibers.
