MARK-LW-03-07NUV Second-Generation On-the-Fly UV Inkjet Coder MARK-LW-03NUV
This product integrates a 355nm UV laser and high-speed galvanometer with efficient water cooling. On-the-fly marking with dynamic focus tracking, intelligent path planning and multiaxis synchronization enable permanent precision marking of glass, ceramics, polymer films and metal coatings during high-speed continuous production.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Wavelength | 355nm |
| Output Average Power [@40KHz] | >3W@40KHz |
| Max Single-pulse energy [@30KHz] | 0.075mJ@30KHz |
| Pulse Repetition Rate | 30-50KHz |
| Pulse width [@40KHz] | <15ns@40KHz |
| Average Power stability [over 12 hours] | <3% over 12 hours |
| Spatial Mode | TEM00 (M²< 1.2) |
| Spot roundness | > 90% |
| Output Aperture Spot Size (6 Times Beam Expansion) | 3mm |
| Beam Divergence Angle | <0.2mRad |
| Beam Pointing Stability | <20µrad/ºC |
| Degree of polarization [Horizontal] | > 100:1 Horizontal |
| Warm-Up Time | <30mins |
| Operating environment Temperature | 15℃-30℃ |
| Operating environment Humidity [non-condensing] | 20 -80 non-condensing |
| Cooling method | Water |
| Volume | 280 mm × 161 mm × 123 mm |
| Weight | 6.4KG |
