Membrane circuit
1 small electrical resistance; 50 large electrical resistance; 5 per cent precision; 10 per cent special precision; 0.5 per cent precision of electrons
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Bore film electrical resistance material | TaN、Pt、NiCr |
| Face resistance | 10Ω/□、50Ω/□、100Ω/□ |
| Precision Absorption | Laser offset (0.5 per cent) |
Datasheet
Please provide your email to download the datasheet.
Invalid email format. Please try again.
