Light pump laser power control system SCR-2kW-220V
The Light Pump Laser Power Control System consists of components such as the master control unit, the 1000-2000 W pulsed lumber light power source, the industrial touch screen, the water cooling-dispersion system, etc.; and the large energy solid laser for the HQF wavelength of the apricot pump. The control system combines different types of tuning Q, MOPA skin-second lasers, guide arm, fibre-optic accessories; they can be widely applied in areas such as spectroscopy analysis, radar sensing, bio
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Power Power | 2000W |
| Power type | Controlled Silicon |
| Program Functions | Touch screen control, RS232 remote communication control, internal and external trigger |
| Show Language Type | Default English, preset multilingual frames |
| Electricity requirements | 220V±10%AC, 50/60Hz, 16A |
| Operational environmental requirements | Temperature 15-30°C relative humidity < 60% |
Applications
Key Features
Datasheet
Supplier Information
