HQF series light pump Qnasecond laser
The HQF series of light-pumping Qnasecond lasers are a compact nanosecond laser; designed with a single lamp double rod; a flash light is long in service; it is easy to replace; the output beam is flattened distribution; a single wavelength/biwavelength output version can be provided; energy can reach 800 mJ and 1.2J, respectively, at the 1064nm wavelength; and fittings such as light arm, control screen, power, water cooler can be provided. The products in this series are structurally compact, s
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Frequency | 1~10Hz |
| Energy | 800mJ@1064nm, 400mJ@532nm; 1200mJ@1064nm, 600mJ@532nm |
| Energy stability | <2%@1064nm, <3%@532nm |
| Horizontal Full-Angle Divergence (1/e²) | <5mrad |
| Vertical Full-Angle Divergence (1/e²) | <5mrad |
| Point to stability °C | <50 |
| Exterior Trigger | <0.5 |
| Luminous diameter | ~9.5; ~10.5mm |
| Crossground Mode | Top Distribution |
| Distortion | Line angle |
| Electricity requirements | 220V/110V±10%AC, 50/60Hz |
| Operational environmental requirements | Temperature 18~35°C, humidity < 75% |
| Wavelength | 1064 / 532nm |
Applications
Key Features
Datasheet
