AWMO-C/D series semiconductor laser module
The AWMO-C/D series semiconductor laser module; multi-channel semiconductor laser modules and drive circuits designed for integrated almond luminous light autonomous design; input-output interfaces that match standards; user-host systems that can be easily embedded; multiwavelength semiconductor laser outputs that achieve high stability and structure. The series is widely used in areas such as spectral detection, material processing, lighting and biomedical treatment; customized and secondary de
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Continuous output power | 3; 5; 10W |
| Average output power ceiling | 15 (AWMO-C) / 30 (AWMO-D)W |
| He's on the wavelength | ±10nm |
| spectral width | <6nm |
| Output Power | 1~5mW |
| The wavelength | 650nm |
| Connection | Fibre interpolation |
| Fibre length | 100±10 (other lengths customizable)cm |
| Numerical aperture | 0.22 |
| Connector | SMA905 |
| Working mode | Continuous/quasi-continuous |
| Light frequency | 0~10kHz |
| The light's wide | 0.05~300ms |
| Dispersion mode | It's cold |
| Control Mode | Simulate 0-5V reconciliation power, TTL 5V space ratio |
| Electricity requirements | 12VDC, 100W |
| Working environment temperature | 10~30℃ |
| Storage temperature requirements | -25~55℃ |
| Storage Humidity Requirements | 0~80% RH |
| Central wavelength | Wavelength options; 450; wavelength options; 635; wavelength options; 650; wavelength options; 675; wavelength options; 695; wavelength options; 755; wavelength options; 785; wavelength options; 808; Wavelength options; 830; wavelength options; 880; wavelength options; 915; wavelength options; 940; wavelength options; 980; wavelength options; 1064; wavelength options; 1320; wavelength options; 1470; wavelength options; 1550; wavelength options; 1720; wavelength options; 1940nm |
