PSNL-A1 instrument

PSNL-A1 instrument

Supplier
Peiport
Part Number
PSNL-A1
Category
Other
Origin
Hong Kong

The PSNL-A1 Acoustic Imaging System is an advanced, easy-to-use device;

Specification Snapshot
Dynamic range, low limit
Less than 15 dB (depending on frequency)
Dynamic range, high limit
120 dB (depending on frequency)
Bandwidth
2-35 kHz
Working temperature storage temperature
-10°C-+ 50°C(14°F-122°F)/; 、-20°C-70°C(-4°F-158°F)
Camera Dimensions Weight
273 x 170 x 125 mm (10.7 x 6.7 x 4.9 inch), 980 g (2.2 lbs)
Battery size and weight
90 x 145 x 65 mm (3.5 x 5.7 x 2.6 inch), 985 g (2.2 pounds) 87 x 65 x 129 mm, 250 g battery box
Request a Quote Download Datasheet
Save to Favorites Save to Favorites

Overview

The PSNL-A1 Acoustic Imaging System is an advanced, easy-to-use device; in routine checks of high-pressure power systems; and in local discharges in fast and efficient detection and positioning equipment. At the same time; the leakage can be accurately detected in compressed gas systems and the economic loss from failure can be assessed. Purpose; * Electrical equipment to detect discharges of equipment in empty circuits; internal equipment in electrical cabinets to detect *gas leaks (compressed gas; gas pipelines); refrigerant leakage characteristics; * Integrated battery design; portable

Specifications

ParameterValue
Acoustic measurements124 low noise MEMS microphones, real-time sound visualization
Dynamic range, low limitLess than 15 dB (depending on frequency)
Dynamic range, high limit120 dB (depending on frequency)
Bandwidth2-35 kHz
Measurement DistanceFrom 0.3 m (1.0ft) to above 130 m (430ft)
Classification and analysis of dischargesPRPD mode, negative dizziness, positive dizziness, floating discharge, surface discharge or internal discharge of components
Recharge location and detectionAutomatically detect 50/60Hz
Snapshot Resolution800 ×480
Video Frame Rate25 fps (optic images)/30 fps (acoustic images)
Zoom2 times digital focus
Wireless data transferIEEE 802.11.b/g/n/ac
Camera power inputStandard input voltage: 12Vdc, Max: 15VDC, 2.5A
Maximum Output13.8V, 4.0A (one battery: 0-17.4 VDC, 0-4.8A 2-3 hours per block)
Working temperature storage temperature-10°C-+ 50°C(14°F-122°F)/; 、-20°C-70°C(-4°F-158°F)
Charging Temperature0°C-+ 40°C(32°F -104°F)
Camera Dimensions Weight273 x 170 x 125 mm (10.7 x 6.7 x 4.9 inch), 980 g (2.2 lbs)
Battery size and weight90 x 145 x 65 mm (3.5 x 5.7 x 2.6 inch), 985 g (2.2 pounds) 87 x 65 x 129 mm, 250 g battery box
Total Weight2.9 kg (6.4 lbs) (including all accessories); and 1.2 kg for camera integrated batteries
