Rangefinder Module
Laser Scanning and Ranging

Rangefinder Module

Supplier
Jiguangceju
Category
Laser Scanning and Ranging
Origin
China

Large range laser ranging industrial module (industrial ranger);

Specification Snapshot
Power Supply Voltage
3.3 V±500 mV( )/ 5-20 V
Laser Beam Divergence
7 mrad
Request a Quote Download Datasheet
Save to Favorites Save to Favorites

Overview

Large range laser ranging industrial module (industrial ranger); use of 900-908 nm human eye safety lasers and LD lasers; range range 3.5-2000; resolution of 0.1 m, accuracy of range 1 m; power supply 3.3V ±500 mV (specify) or 5-20V; communication mode support TTL/RS-232/RS-485/CAN; support industrial customization and secondary development

Specifications

ParameterValue
Laser typeLD
Distance Measurement Range3.5-2000 m
Distance Resolution0.1 m
Inclination measurement( )/±90°
Power Supply Voltage3.3 V±500 mV( )/ 5-20 V
Static power consumption120mw
Optical caliber25 mm( )/35 mm
Laser Beam Divergence7 mrad

Applications

Industrial ranging (support for industrial customization and secondary development); page display for platforms such as drones

Key Features

2000 Metrography; support for industrial customization; support for secondary development; high stability; high precision; fast measurement

Datasheet

Please provide your email to download the datasheet.

Your name
Email Address

Invalid email format. Please try again.

Send Request

Supplier Information

Ji
Jiguangceju
View Supplier →
Tianjin Lookout Photoelectric Technology Co., Ltd. is a holding company of IBE Group, an OEM service provider focusing on optical product design, and a high-tech company mainly engaged in R&D, manufacturing, and trade. The company's main products are laser rangefinders, industrial ranging modules, infrared thermal imagers, high-definition telescopes, industrial transmitters, and wireless communication terminal equipment. The company has a high, precise, and advanced R&D team dedicated to the design and manufacturing of high-end optical, mechanical, and electrical products and the development of solutions. Especially in the field of laser rangefinders, the company focuses on the industry, pursues customer experience, and has created a high-end brand of networked rangefinders, Hawkeye. The HK series laser rangefinders based on Hawkeye integrate ranging, angle measurement, and height measurement functions, and have breakthroughly developed Bluetooth communication between the rangefinder and mobile phones. The built-in APP allows users to locate at any time and realize voice broadcast of straight-line, area, and other measurement functions; the HK series rangefinders have a ranging accuracy of 0.1m, which is at the international leading level and has obtained calibration and metrology certification from the National Photoelectric Rangefinder Testing Center. The company will adhere to the concept of "customer first, quality assurance" and create first-class brand value.
