MU9602 <0.2dB >50dB
MU9602, RS232
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Band | 1250-1650nm( ) |
| Operating Mode | Full polarization-state mode, three-loop emulation mode, hybrid mode |
| Operating Temperature | +10~+40℃ |
| Storage Temperature | -15~+70℃ |
| Weight | 4kg |
| Dimensions | 235104300 mm( ) |
| Command response time | <10mS |
| Trigger time | <20uS |
| Fiber optic connector | FC/APC (can be customized according to customer) |
| Interface plug-in specifications | 3.81mm-6P (module only) |
| Measurement speed | 250mS |
| AC power input | 220V，50Hz |
| Boot warm-up time | 15min |
| Power | max:500mW |
