QSD0620
6-inch dicing machine: QSD0620, QSD0630, QSD0636. Products suitable for processing by this equipment include silicon wafers, plastic packages (QFN, BGA, etc. ), PCB boards, ceramic substrates (alumina, zirconia, etc. ), oxide ceramics (heat-sensitive, pressure-sensitive, photoresistor), glass, quartz, lithium niobate, lithium tantalate, magnetic materials, etc
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Processing Size | Φ6" 60X160mm |
| Speed Range | 5000-50000RPM |
| Power | 1.5KW |
| X Axis Dicing Speed | 0.01-400mm/s |
| Y Axis Method | + |
| Y Axis Resolution | 0.0001mm |
| Y Axis Single-Step Accuracy | 0.002/5mm |
| Y Axis Cumulative Accuracy | 0.004/165mm |
| Z Axis | 0.001mm |
| T Axis Method | DD |
| T Axis Rotation Angle Range | 0-320° |
| T Axis Resolution | 0.0004° |
| T Axis Accuracy | 3" |
| Function Configuration | · · · · · · Automatic ·NCS |
| Cutting Water | 0.2-0.4MPa: 3L/min |
| Cooling Water | 0.2-0.4MPa: 1.5L/min |
| Exhaust Air Volume | 1.5m³/min |
| Outline Dimensions | 640X908X1650mm |
| Processing Size | Φ6" 160X160mm |
| Speed Range | 5000-50000RPM |
| Power | 1.8KW |
| X Axis Dicing Speed | 0.01-400mm/s |
| Y Axis Method | + |
| Y Axis Resolution | 0.0001mm |
| Y Axis Single-Step Accuracy | 0.002/5mm |
| Y Axis Cumulative Accuracy | 0.004/165mm |
| Z Axis | 0.001mm |
| T Axis Method | DD |
| T Axis Rotation Angle Range | 0-320° |
| T Axis Resolution | 0.0004° |
| T Axis Accuracy | 3" |
| Function Configuration | · · · · · · Automatic ·NCS |
| Cutting Water | 0.2-0.4MPa: 3L/min |
| Cooling Water | 0.2-0.4MPa: 1.5L/min |
| Exhaust Air Volume | 1.5m³/min |
| Outline Dimensions | 640X908X1650mm |
| Processing Size | Φ6" 160X160mm |
| Speed Range | 5000-50000RPM |
| Power | 1.8KW |
| X Axis Dicing Speed | 0.01-400mm/s |
| Y Axis Method | + |
| Y Axis Resolution | 0.0001mm |
| Y Axis Single-Step Accuracy | 0.002/5mm |
| Y Axis Cumulative Accuracy | 0.004/165mm |
| Z Axis | 0.001mm |
| T Axis Method | DD |
| T Axis Rotation Angle Range | 0-320° |
| T Axis Resolution | 0.0004° |
| T Axis Accuracy | 3" |
| Function Configuration | · · · · · · Automatic ·NCS |
| Cutting Water | 0.2-0.4MPa: 3L/min |
| Cooling Water | 0.2-0.4MPa: 1.5L/min |
| Exhaust Air Volume | 1.5m³/min |
| Outline Dimensions | 640X908X1650mm |
| Dicing Straightness | 0.002mm/150mm |
| Worktable Flatness | 0.006mm/Φ150mm |
| X Y Axis Perpendicularity | 0.01mm/150mm |
| Y Axis Step Accuracy - Single-Step Accuracy | 0.002/5mm |
| Y Axis Step Accuracy - Full-Travel Cumulative Accuracy | 0.005/160mm |
| Spindle Flange Accuracy - Horizontal Direction | 0.002mm |
| Spindle Flange Accuracy - Vertical Direction | 0.002mm |
| Cutting Water | 1. Cutting Water ±2°C, 0.2-0.4MPa, 2 φ12mm, 205mm. 3 φ32mm, 460mm |
| Spindle Cooling Water | 1. Cooling Water ( Spindle ), ±2°C, 0.2-0.4MPa. 2. Cooling Water: φ8mm, 205mm |
| Mist Extraction Pipe | Mist Extraction Pipe φ60mm, 1.5m³/min, 1120mm |
