Cylindrical Stainless Steel Vacuum Chamber

Output Mode: 恒流源 & 恒流+恒压源 Single-channel Constant Current Source Output Current Range: 50~2000mA Adaptive Voltage Range: 0~5V

The LASER X COC Aging Machine is a high-density burn-in and reliability test system designed for Chip-on-Carrier (COC) laser devices. The cabinet-type system integrates 10 aging units, each capable of loading 4 independently controlled aging drawers, and is compatible with 48/32-position fishbone fixtures that support offline loading. It provides constant current source and constant current + constant voltage source output modes with high precision and long-term stability, combined with TEC temperature control covering 60~100°C, ensuring accurate, stable and efficient long-term aging tests for laser diodes used in optical communication and optoelectronic manufacturing.

Total Number of Channels: 384 Total Number of Layers: 8 Power Supply Channels per Layer: 2

The LASER X BT-4343 is a high-capacity industrial laser COS (Chip on Submount) aging machine designed for burn-in and reliability testing of high-power semiconductor laser chips. The system integrates 384 test channels across 8 layers, with 2 power supply channels per layer and 24 COS per channel connected in series. It supports both CW and QCW aging modes with a minimum QCW pulse width of 3ms, a current output range of 1~80A, and an adaptive voltage range of 20~50V. Each COS is independently monitored online for optical power, temperature and voltage, enabling real-time tracking of the aging status. A reserved wavelength reading interface allows chip junction temperature calibration via an external spectrometer. The system adopts water-cooling temperature control, and is equipped with comprehensive alarm and protection mechanisms, including cooling water flow over-limit alarm and leakage detection, ensuring the safety of personnel, chips and equipment.

Suitable Incoming Material Types: Gel-Pack / Waffle Pack / 蓝膜 Suitable Devices: COC, Lens, PLC等 Conversion Capability 1: 6寸蓝膜—鱼骨夹具之间 相互转换

The LASER X Automatic Transfer Machine is a high-precision automated handling system designed for the mutual conversion and transfer of optoelectronic devices among different carrier formats. It supports incoming materials in Gel-Pack, Waffle Pack, and blue film formats, and is suitable for devices such as COC, Lens, and PLC. The machine enables bidirectional conversion between 6-inch blue film and fishbone fixtures, 2-inch GelPak and fishbone fixtures, 6-inch blue film and 2-inch GelPak, as well as blue film-to-blue film and GelPak-to-GelPak transfers. Equipped with OCR character reading, system data connection, and COC sorting functions, it achieves a repeat positioning accuracy of ±10μm for devices sized 1.5*1.5mm~2.5*2.5mm, making it an ideal solution for automated optoelectronic device packaging and manufacturing.

Output Mode: CW & Pulse Output Current Range: 0~3A / 0~1A Adaptive Voltage Range: 0~7V / 0~18V

The High Power COS Testing Machine is a fully enclosed, integrated test platform designed for comprehensive characterization of high-power laser diode COS (Chip on Submount) devices, including pump lasers and industrial lasers. It combines a precision CW & Pulse current source (0~3A / 0~1A) with optical power measurement, spectrum analysis (600~1700nm), far-field scanning, polarization extinction ratio (PER) testing, and TEC-based temperature control (20~100℃) in a single sealed chamber with a settable test environment temperature of 0~100℃. The machine supports LIV, PER, spectrum and far-field tests in one station, and its test fixtures are fully compatible with burn-in machines, enabling seamless process flow from device testing to aging.
