ITU-T Light Source

ITU-T Light Source

Supplier
Hoyatek
Category
Photon Sources
Origin
China
Specification Snapshot
DWDM(1527~1590)CWDM(1270~1610)nm
35~45 (typ. 40)dB
-20~+60℃
-20~+70℃
5~95%
1/4.5W
Request a Quote Download Datasheet Chat
Save to Favorites Save to Favorites

Overview

The DFB laser module is a continuous light emitting, high output optical power, narrow linewidth distributed feedback (DFB) semiconductor laser optoelectronic module developed for wavelength division multiplexing communication systems.The wavelength range meets ITU recommended standards, the output optical side mode suppression ratio is high, and the relative intensity noise is low.The module has built-in high-precision temperature control circuit and automatic power APC drive circuit, making the module have high wavelength stability and power stability.Complete safety design such as built-in overcurrent/overvoltage protection, strict process control and testing procedures enable the product to be used in fiber optic communication systems reliably for a long time.

Specifications

ParameterValue
DWDM(1527~1590)CWDM(1270~1610)nm
10/100mW
±0.005/±0.01dB
±0.01/±0.03dB
1MHz
35~45 (typ. 40)dB
-140/-150
30/35dB
-20~+60℃
-20~+70℃
5~95%
Desktop: 300×220×90
Module: DC 5V; desktop: AC220V±10%, 50Hz, 20W%
SMF -28
FC/APC, FC/PC or customer customized
Low Level Alarm Low Level Alarm

Applications

Optical device production and testing; Optical communication system testing; Optical fiber sensing system; HFC, CATV network; Teaching experiment system; Optical network detection; Optical sensing and optical communication experiment; Typical spectra:; 1550nm spectrum; 1570nm spectrum; 1578nm spectrum; 1653nm spectrum; 1653nm spectrum

Key Features

High power output (adjustable power output); Excellent power stability and wavelength stability; ITU-T recommended standard channels; Channel spacing 25/50/100GHz; Customizable (center wavelength, output power); High stability; Ultra-narrow linewidth; Band remote control available; Wavelength adjustment available; Power adjustment available; Special wavelengths available
