MK Series Handheld Thermal Imager
The MK Series Handheld Thermal Imager is designed for outdoor use, offering high-resolution thermal imaging and advanced features for various applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Resolution MK-IR | 384×288/12μm |
| Resolution MK-IRS | 640×512/12μm |
| Resolution MK-LR | 640×512/12μm |
| Lens Focal Length MK-IR | 19mm |
| Lens Focal Length MK-IRS | 25mm |
| Lens Focal Length MK-LR | 35mm |
| Field of View MK-IR | 19.5°×14.7° |
| Field of View MK-IRS | 13.8°×10.4° |
| Field of View MK-LR | 10.5°×7.9° |
| Detection Range MK-IR | 650m |
| Detection Range MK-IRS | 850m |
| Detection Range MK-LR | 1200m |
| Operating Band | 8μm-14μm |
| Exit Pupil Distance | 20mm |
| NETD | ≤25mk@300K |
| Display | 0.39'' OLED 1024×768 |
| Digital Zoom | 1x, 2x, 4x |
| Protection Level | IP67 |
| Battery Type | 1×18650 rechargeable battery |
| Battery Life | ≥7h |
| Interface | Type-C |
| Weight MK-IR | ≤470g |
| Weight MK-IRS | ≤515g |
| Operating Temperature | -20°C~50°C |
| Dimensions MK-IR | 19mm/180m 25mm/230m 35mm/350m/430m |
