Unknown Optical Component
This is an optical component designed for precision applications, featuring a robust design and high-quality materials.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Outer Diameter | 72.5mm |
| Front End Diameter | 61mm |
| Total length | 77.43mm (max78.33, min76.7) |
| Thread Interface | M45×1-6g |
| Front End Length | 33.6mm |
| Rear End Length | 39.5mm |
| Front End Thickness | 15mm |
| Rear End Thickness | 15.5mm |
Applications
Key Features
Datasheet
