6712 Type
The 6712 Type is a compact, chemically resistant solenoid valve designed for precise fluid control in medical and analytical applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Size Features | Valve width 7mm |
| Material | FFKM |
| Material | EPDM |
| Valve Body | PEEK |
| Valve Body | PPS |
| Internal Volume | Flow channel: 2μl, Dead volume: approx. 5μl |
| Nominal Diameter | DN0.8 |
| Circuit Function | A |
| Cumulative Service Life | 30 million switching cycles (tested under laboratory conditions) |
| Pressure Range DN0.8 | FFKM 0-3bar, EPDM 0-2.5bar |
| Pressure Range DN0.4 | FFKM 0-5bar, EPDM 0-5bar |
| Outlet Pressure (Back Pressure) DN0.8 | FFKM 0-1.2bar, EPDM 0-0.8bar |
| Outlet Pressure (Back Pressure) DN0.4 | FFKM 0-1.5bar, EPDM 0-1.5bar |
| Switching Noise | 36dB(A) |
| Response Time | 0.9ms (pressure increase 0-10%), 1.8ms (pressure decrease 100-90%) |
| Operating Voltage | 12VDC, 24VDC |
| Power Consumption | 0.9W |
| Frequency | 50Hz |
| Voltage Deviation | ±10% (including residual ripple) |
| Medium Temperature | FFKM: +10°C to +55°C, EPDM: 0°C to +55°C |
| Viscosity | Max. 21mm²/s |
| Connection Method | 2503 Type plug connection, AWG26, 500mm (optional) |
| Pipeline Interface | Burkert flange (7x18.2mm) |
| Protection Class | IP10 with 2503 Type plug connection, IP40 with 2503 Type housing |
| Food and Beverage/Hygiene | FDA (EPDM material complies with FDA standards) |
| Ambient Temperature | FFKM: +10°C to +55°C, EPDM: 0°C to +55°C |
