6712 Type
The 6712 Type solenoid valve is a compact and chemically resistant valve designed for precise fluid control in medical and analytical applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Material | FFKM |
| Material | EPDM |
| Valve Body | PEEK |
| Valve Body | PPS |
| Internal Volume | Flow path: 2μl, Total internal volume: ~5μl |
| Nominal Diameter | DN0.8 |
| Circuit Function | A |
| Service Life | 30 million switching cycles (based on laboratory testing) |
| Pressure Range DN0.8 | FFKM 0-3bar, EPDM 0-2.5bar |
| Pressure Range DN0.4 | FFKM 0-5bar, EPDM 0-5bar |
| Outlet Pressure DN0.8 | FFKM 0-1.2bar, EPDM 0-0.8bar |
| Outlet Pressure DN0.4 | FFKM 0-1.5bar, EPDM 0-1.5bar |
| Switching Noise | 36dB(A) |
| Response Time | 0.9ms (pressure increase 0-10%), 1.8ms (pressure decrease 100-90%) |
| Operating Voltage | 12VDC, 24VDC |
| Power Consumption | 0.9W |
| Frequency | 50Hz |
| Voltage Deviation | ±10% (including ripple) |
| Medium Temperature FFKM | 10°C-55°C |
| Viscosity | Max 21mm²/s |
| Connection Type | 2503 Type cable plug, AWG24, 500mm |
| Protection Class | IP10 with 2503 plug, IP40 with housing |
| Food and Beverage/Hygiene | FDA (EPDM material complies with FDA standards) |
| Ambient Temperature FFKM | 10°C-55°C |
| Dimensions | Refer to technical drawings |
| Connection Base | UNF 1/4 inch-28 PEEK |
| Order Numbers | 00272331, 00320504, 00273235, 00394634, 20094500, 20001724 |
