Cool Drawer Single Sensor
The Cool Drawer Single Sensor allows convenient side installation of crystals, ideal for systems with limited front access. It features a water-cooled housing for thermal shielding, ensuring excellent crystal performance.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Material | Stainless steel |
| Material | Teflon |
| Material | ceramic |
| Material | beryllium nickel |
| Cooling Water | 0.2GPM using 1/8in O.D. tube |
| Electrical Connection | One standard female BNC on atmosphere side |
| Crystal | Industry standard 0.550in diameter |
| Air Supply | Shuttered sensors require 55–60psi regulated |
| 1in Bolt and Compression Fitting Materials | 304 stainless steel, Teflon, ceramic, beryllium nickel, VITON |
| 1in Bolt and Compression Fitting Temperature | Operational environment to 300°C with water cooling or 165°C without |
| 1in Bolt and Compression Fitting Mounting | 1.015in ±0.010in diameter aperture |
| CF40 Termination Materials | 304 stainless steel, Teflon, ceramic, beryllium nickel |
| CF40 Termination Temperature | Operational environment to 450°C with water cooling or 200°C without |
| CF40 Termination Mounting | Mates with 2¾in ConFlat type flanges with 1.375in I.D. min |
