ScopeCorder Plug-in Modules
ScopeCorder plug-in modules are designed for high-speed, high-precision measurement and analysis of electrical signals, offering versatile functionality for various applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Sample Rate | 200MS/s, 100MS/s, 10MS/s, 1MS/s |
| Resolution | 14bit, 12bit, 16bit |
| Bandwidth | 40MHz, 20MHz, 3MHz, 300kHz |
| Number of Channels | 2, 4, 16 |
| Isolation | Isolated, Non-Isolated |
| Maximum Input Voltage | 1000V DC, 600V DC, 42V DC |
| DC Accuracy | ±0.5%, ±0.25% |
| Input Impedance | 1MΩ, 35pF |
| Temperature Measurement Range | -200°C to 2300°C |
| Temperature Measurement Accuracy | ±0.1% of reading ±1°C |
| Frequency Range | 0.01Hz to 500kHz |
| Weight | Approx. 270g, 280g, 310g |
Applications
Key Features
Datasheet
Supplier Information
Related Products
-
High Voltage Single Contact Connectors
Accessories
Lemo-China
Outer Shell Material: Brass (UNS C38500) Inner Shell Material: Brass (UNS C38500) Earthing Crown Material: Beryllium Copper (UNS C17300)
LEMO's high voltage single contact connectors are designed for reliable and secure connections in high voltage applications. These connectors feature a push-pull self-latching system, ensuring safe and quick mating and unmating. They are available in various series, including Y, S, E, and 05, offering solutions for diverse industrial and scientific applications.
-
Fiber Optic Splice Tray Cover
Accessories
Yokogawa
Color: Gray Material: Engineering plastic Mounting Method: Screw fixing
The Fiber Optic Splice Tray Cover is a rectangular protective cover made of gray engineering plastic, designed to shield fiber optic splice trays installed in optical distribution frames (ODF), fiber optic terminal boxes, and splice closures. Based on the product image, the cover is secured with two captive Phillips screws located on the left and right ends, enabling quick installation and removal during fiber splicing and maintenance operations. Two small rectangular positioning slots near the bottom edge help lock the cover onto the splice tray base, preventing dust, accidental contact, and mechanical damage to the spliced fibers and splice protection sleeves inside. Its low-profile, rounded-edge structure supports high-density fiber management while keeping the routing area neat and well protected. Note: as the source material is image-based only, detailed mechanical dimensions and material grade are not provided.
-
YOKOGAWA Handheld Optical Test Instrument Protective Carrying Case
Accessories
Yokogawa
Brand: YOKOGAWA Product Type: Protective Carrying Case / Holster Color: Light Gray
This is a dedicated soft protective carrying case (holster) designed for YOKOGAWA handheld optical test instruments such as optical power meters, light sources and compact OTDRs. The case is made of flexible light-gray elastomer material that wraps around the instrument body, providing shock absorption and scratch protection during field operation and transportation. The front-open structure keeps the display and keypad fully accessible while the instrument remains inside the case. A reinforced top frame with two mounting/attachment holes and an integrated hand strap allows the operator to carry the instrument securely or hang it during on-site measurements. The embossed YOKOGAWA logo on the top indicates it is an original manufacturer accessory, precisely molded to fit the instrument outline, with an extended bottom bumper for extra drop protection.
-
Tactical Flashlight Leather Holster Pouch
Accessories
Yokogawa
Product Type: Flashlight holster / carry pouch Main Material: PU leather Strap Material: Nylon webbing
The Tactical Flashlight Leather Holster Pouch is a black PU leather carry case designed to hold and protect handheld optoelectronic devices such as LED flashlights, tactical torches and laser pointers. It features nylon webbing straps with hook-and-loop closures at the top and bottom to secure the device, reinforced edge stitching for durability, and a rear belt loop/strap that allows quick attachment to a belt, waistband, backpack strap or tactical vest. Lightweight and compact, it keeps the flashlight within easy reach while freeing the user's hands and pockets, making it suitable for outdoor, patrol, security and everyday carry (EDC) use.
-
Photodetector Module
Accessories
Yokogawa
Package Type: Rectangular housing Optical Window: Large-area rectangular entrance window Electrical Interface: Side-mounted connector/lead pins
Based on the provided material (a line-drawn product image without legible text, model number, or specification table), this product is a rectangular, window-type photodetector device. It features an elongated rigid housing with a large-area optical entrance window on the front face for receiving incident light, and a compact side-mounted electrical connector/lead-pin block for power supply and signal output. The sealed package structure provides mechanical protection and stable photoelectric conversion performance, making it suitable for integration into optical measurement and instrumentation systems. Detailed optical and electrical specifications are not readable in the source image and should be confirmed with the manufacturer's datasheet.
