ScopeCorder Plug-in Modules
ScopeCorder plug-in modules are designed for high-speed, high-precision measurement and analysis of electrical signals, strain, temperature, acceleration, and logic signals.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Sample Rate | 200MS/s, 100MS/s, 10MS/s, 1MS/s |
| Resolution | 14bit, 12bit, 16bit |
| Bandwidth | 40MHz, 20MHz, 3MHz, 300kHz |
| Number of Channels | 2, 4, 16 |
| Isolation | Isolated, Non-Isolated |
| Maximum Input Voltage | 1000V DC, 600V DC, 42V DC |
| DC Accuracy | ±0.5%, ±0.25% |
| Input Coupling | AC |
| Input Coupling | DC |
| Input Coupling | GND |
| Input Impedance | 1MΩ, 2MΩ |
| Temperature Measurement Range | -200°C to 2300°C |
| Acceleration Measurement Range | 4mA/22V |
| Logic Input Voltage | ±35V, 250Vrms |
| Frequency Measurement Range | 0.01Hz to 500kHz |
| Power Measurement Range | 1000V DC, 600Vrms |
| Noise Rejection | 80dB (50/60Hz) |
| Weight | Approx. 270g to 310g |
Applications
Key Features
Datasheet
Supplier Information
Related Products
-
