702915/702916 Current Probes
The 702915 and 702916 current probes are designed for precise measurement of standby current and ripple current in circuit designs, offering high sensitivity for microcurrent measurement and wide bandwidth capabilities.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Bandwidth 702915 | DC to 50MHz (-3dB) |
| Bandwidth 702916 | DC to 120MHz (-3dB) |
| Rise Time 702915 | ≤7ns |
| Rise Time 702916 | ≤2.9ns |
| Delay Time 702915 | 12ns (typical) |
| Delay Time 702916 | 12ns (typical) |
| Maximum Connected Current 702915 | 30Arms |
| Maximum Connected Current 702916 | 30Arms |
| Range 702915 | 30A, 5A, 0.5A |
| Range 702916 | 30A, 5A, 0.5A |
| Output Voltage Ratio 702915 | 0.5A range: 1V/A, 5A range: 0.1V/A, 30A range: 0.01V/A |
| Output Voltage Ratio 702916 | 0.5A range: 1V/A, 5A range: 0.1V/A, 30A range: 0.01V/A |
| Maximum Peak Current 702915 | ±50Apeak (<20kHz), ±30Apeak (<10MHz) |
| Maximum Peak Current 702916 | ±50Apeak (<20kHz), ±30Apeak (<10MHz) |
| Operating Temperature Range | -40°C to +40°C, <80% RH |
| Storage Temperature Range | -40°C to +70°C, <80% RH |
| Dimensions | 115mm x 20mm x 10mm |
| Weight | Approx. 370g |
