702915/702916 Current Probes
The 702915 and 702916 current probes are designed for precise measurement of standby current and inrush current in circuits, with wide measurement ranges of 30A, 5A, and 0.5A.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Frequency Range 702915 | DC to 50MHz (-3dB) |
| Frequency Range 702916 | DC to 120MHz (-3dB) |
| Rise Time 702915 | ≤7ns |
| Rise Time 702916 | ≤2.9ns |
| Delay Time 702915 | 12ns (typical) |
| Delay Time 702916 | 12ns (typical) |
| Maximum Current 702915 | 30Arms |
| Maximum Current 702916 | 30Arms |
| Maximum Current for 5A Range | 5Arms |
| Maximum Current for 0.5A Range | 0.5Arms |
| Output Voltage Ratio 30A Range | 0.1V/A |
| Output Voltage Ratio 5A Range | 1V/A |
| Output Voltage Ratio 0.5A Range | 10V/A |
| Accuracy 30A Range | ±3.0% rdg ±1mV, ±1.0% rdg ±1mV (10mA-30Arms) |
| Accuracy 5A Range | ±3.0% rdg ±1mV, ±1.0% rdg ±1mV (1mA-5Arms) |
| Accuracy 0.5A Range | ±3.0% rdg ±1mV, ±1.0% rdg ±1mV (0.1mA-0.5Arms) |
| Maximum Peak Current 30A Range | ±50Apeak (<60Hz) |
| Maximum Peak Current 5A Range | ±7.5Apeak (<10MHz) |
| Maximum Peak Current 0.5A Range | ±0.75Apeak (<10MHz) |
| Noise | ≤75μArms, 60μArms (typical) |
| Operating Temperature Range | -40°C to +40°C, 80% RH |
| Storage Temperature Range | -20°C to +60°C |
| Storage Humidity Range | 80% RH |
| Weight | Approx. 370g |
