OTDR AQ7280 Series
The AQ7280 series is a modular optical time domain reflectometer (OTDR) designed for maximum configuration flexibility, offering multi-fiber testing and high performance for optical network installation and maintenance.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Dimensions (W×H×D) AQ7280 | 287×210×80mm |
| Weight AQ7280 | 2.8kg |
| Display Size AQ7280 | 8.4inch |
| Battery Operating Time AQ7280 | 15hours |
| Charging Method AQ7280 | AC Adapter |
| LAN AQ7280 | Yes |
| Wireless LAN AQ7280 | Optional |
| Multi-fiber Testing AQ7280 | Yes |
| Stable Light Source AQ7280 | Optional |
| Low Reflection Light Source AQ7280 | Optional |
| Optical Power Meter AQ7280 | Optional |
| Optical Time Domain Reflectometer AQ7280 | Yes |
| Automatic Fiber Connector Detection AQ7280 | Yes |
| Dimensions (W×H×D) AQ1210 | 210×148×69mm |
| Weight AQ1210 | 1kg |
| Display Size AQ1210 | 5.7inch |
| Battery Operating Time AQ1210 | 10hours |
| Charging Method AQ1210 | USB power adapter |
| LAN AQ1210 | No |
| Wireless LAN AQ1210 | Optional |
| Multi-fiber Testing AQ1210 | Yes |
| Stable Light Source AQ1210 | Optional |
| Low Reflection Light Source AQ1210 | Optional |
| Optical Power Meter AQ1210 | Optional |
| Optical Time Domain Reflectometer AQ1210 | Yes |
| Automatic Fiber Connector Detection AQ1210 | Yes |
| Dimensions (W×H×D) AQ1000 | 185×116×56mm |
| Weight AQ1000 | 660g |
| Display Size AQ1000 | 5.0inch |
| Battery Operating Time AQ1000 | 10hours |
| Charging Method AQ1000 | USB power adapter |
| LAN AQ1000 | No |
| Wireless LAN AQ1000 | No |
| Multi-fiber Testing AQ1000 | No |
| Stable Light Source AQ1000 | Optional |
| Low Reflection Light Source AQ1000 | Optional |
| Optical Power Meter AQ1000 | Optional |
| Optical Time Domain Reflectometer AQ1000 | Yes |
| Automatic Fiber Connector Detection AQ1000 | No |
