Optical Time Domain Reflectometer (OTDR)
Yokogawa's OTDR series offers high precision and reliable optical fiber measurement solutions, including modular, multifunctional, and entry-level models.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Dimensions (W×H×D) AQ7280 | 287×210×80mm |
| Dimensions (W×H×D) AQ1210 | 210×148×69mm |
| Dimensions (W×H×D) AQ1000 | 185×116×56mm |
| Weight AQ7280 | 2.8kg |
| Weight AQ1210 | 1kg |
| Weight AQ1000 | 660g |
| Display Size AQ7280 | 8.4inch |
| Display Size AQ1210 | 5.7inch |
| Display Size AQ1000 | 5.0inch |
| Battery Operating Time AQ7280 | 15小时 |
| Battery Operating Time AQ1210 | 10小时 |
| Battery Operating Time AQ1000 | 10小时 |
| Charging Method AQ7280 | AC Adapter |
| Charging Method AQ1210 | USB power adapter |
| Charging Method AQ1000 | USB power adapter |
| Wavelength Range AQ7280 | 1310nm, 1550nm, 1625nm |
| Wavelength Range AQ1210 | 1310nm, 1550nm, 1625nm |
| Wavelength Range AQ1000 | 1310nm, 1550nm |
| Dynamic Range AQ7280 | 32dB-50dB |
| Dynamic Range AQ1210 | 32dB-46dB |
| Dynamic Range AQ1000 | 32dB-38dB |
| Fiber Type AQ7280 | Single-mode, Multi-mode |
| Fiber Type AQ1210 | Single-mode |
| Fiber Type AQ1000 | Single-mode |
| Modular Design AQ7280 | Yes |
| Modular Design AQ1210 | No |
| Modular Design AQ1000 | No |
| Smart Mapper AQ7280 | Yes |
| Smart Mapper AQ1210 | Yes |
| Smart Mapper AQ1000 | No |
| Multi-tasking Mode AQ7280 | Yes |
| Multi-tasking Mode AQ1210 | Yes |
| Multi-tasking Mode AQ1000 | No |
| Stable Light Source AQ7280 | Yes |
| Stable Light Source AQ1210 | Yes |
| Stable Light Source AQ1000 | No |
| Low Reflection Source AQ7280 | Yes |
| Low Reflection Source AQ1210 | Yes |
| Low Reflection Source AQ1000 | No |
| Optical Power Meter AQ7280 | Yes |
| Optical Power Meter AQ1210 | Yes |
| Optical Power Meter AQ1000 | No |
| OTDR AQ7280 | Yes |
| OTDR AQ1210 | Yes |
| OTDR AQ1000 | Yes |
| Automatic Fiber Identification AQ7280 | Yes |
| Automatic Fiber Identification AQ1210 | Yes |
| Automatic Fiber Identification AQ1000 | No |
| Wireless LAN AQ7280 | Yes |
| Wireless LAN AQ1210 | Yes |
| Wireless LAN AQ1000 | No |
| File Transfer AQ7280 | Yes |
| File Transfer AQ1210 | Yes |
| File Transfer AQ1000 | Yes |
