MPA-200
The MPA-200 is a multi-channel optical power monitor designed for data centers, communication equipment, and optical interconnect monitoring. It features a slim 1U rack-mount design, supporting up to 64 channels of optical power monitoring with high efficiency. The device is compatible with MPO optical connectors and supports simultaneous monitoring of multiple optical signals. It is ideal for 100G optical transmission systems and ensures high accuracy with less than 10% error for general optical power meters.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Optical Input Ports | Options: 8,16,32,64 |
| Operating Wavelength Range | 1260-1610nm |
| Optical Input Power | -85dBm to +0dBm |
| Optical Noise Limit | Max.-90dBm |
| ADC Bit | Typ.16(14) |
| Data Sampling Rate | Max.15,625Samples/s |
| PD Response Bandwidth | Max.30kHz(typical) |
| Linearity | +/-0.4dB Typ.+/-0.3 |
| Optical Fiber | SMF TUT-T G.652 |
| Digital Input & Output | USB*2 ports |
| A/D Converter Components | MC USB-2637 Measurement Computing Corporation |
| Electrical Input Ports | BNC connector x 4 ports |
| Fan Motor Monitoring | MC USB-2637 Digital I/O Port A bit 0 |
| Optical Connector | LC/SC/MPO |
| Dimensions | W482.6mm x D506mm x H43.65mm |
| Power Consumption | Max.25W |
| Operating Temperature | +15 to +35°C |
| Warranty | 1 year |
