FemtoFiber smart 780 PT
The FemtoFiber smart 780 PT is a femtosecond fiber laser designed for 2-photon imaging solutions, offering compact, portable, and cost-effective performance.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Center Wavelength | 780±10nm |
| Average Power | >40mW (typ. 50mW) |
| Repetition Rate | 100±1MHz |
| Pulse Duration | <80fs (typ. 70fs) |
| Beam Shape | TEM00 M2<1.2 |
| Fiber Delivery | Fiber pigtail with metal shield tubing, non-detachable from laser module, >2m long, FC/APC connector |
| SHG Module | Miniaturized SHG module, detachable with FC/APC socket |
| PC Interface | USB |
| Operating Temperature Range | 15..40°C |
| Environment Humidity | Non-condensing |
| Voltage | 12V DC |
| Power Consumption | <20W |
| Laser Module Dimensions | 50x135x194mm³ |
| SHG Module Dimensions | 20x20x80mm³ |
| Weight | <2.2kg (SHG<100g) |
