ACS-800P
The ACS-800P is a high-performance optical inspection system designed for precise and efficient quality control in various industrial applications.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Dimensions | 2000mm×1500mm×1800mm |
| Power | 5kW |
| Inspection Accuracy | ±0.01mm |
| Inspection Speed | 500 units/hour |
| Operating Temperature | 10°C-40°C |
| Storage Temperature | -20°C-60°C |
| Interface Type | USB |
| Interface Type | Ethernet |
| Supported File Formats | JPEG |
| Supported File Formats | PNG |
| Supported File Formats | BMP |
Applications
Key Features
Datasheet
Supplier Information
