DLSN-160/DLSN-210 Linear Motor Stage
The DLSN-160 and DLSN-210 are high-precision linear motor stages designed for applications requiring accurate positioning and smooth motion. These stages are constructed with aerospace-grade aluminum and feature advanced linear motor technology for superior performance.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Travel Range DLSN-160 | 160mm |
| Travel Range DLSN-210 | 210mm |
| Main Material | Aerospace aluminum |
| Surface Treatment | Anodizing |
| Guide | Ultra-precision cross roller guide |
| Maximum Speed | 300mm/s |
| Maximum Acceleration | 0.5g |
| Bidirectional Repeatability | ±0.15μm |
| Straightness and Flatness | ±1.5μm |
| Yaw | ±5arcsec |
| Pitch | ±5arcsec |
| Drive Motor | Linear motor |
| Central Load | 50kg |
| Positioning Accuracy | ±0.5μm |
| Control Mode | Closed-loop |
| Weight DLSN-160 | 5.4kg |
| Weight DLSN-210 | 16.8kg |
| Rated current | 2.6A |
