EB-FCP-200-200-0792-03
This high-power fiber-coupled laser module is designed for precision applications requiring stable wavelength and high reliability.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Wavelength Tolerance | ±3 |
| Spectral Width (FWHM) | 3-3.5 |
| NA@95% Powerin | 0.16-0.17 |
| Fiber Core | 197-203 |
| Fiber Cladding | 219-223 |
| Power Conversion Efficiency | 45 |
| Wavelength Temperature Coefficient | 0.33 |
| Anti Reflection Wavelength Range | 1030-1200 |
| Soldering Temperature | 260(10sec) |
Applications
Key Features
Datasheet
Supplier Information
