EB-FCP-1200-300-0976-03
High-power fiber-coupled laser module with 1200W output power, designed for industrial applications requiring reliable and efficient laser pumping.
Save to Favorites
Overview
Specifications
| Parameter | Value |
|---|---|
| Center Wavelength | 976nm |
| Wavelength Tolerance | ±3nm |
| Output Power | 1200W |
| Spectral Width (FWHM) | 5nm |
| Numerical aperture | 0.17 |
| Fiber Core | 300μm |
| Fiber Connector | Pigtail |
| Fiber Length | 2m |
| Power Conversion Efficiency | 50% |
| Threshold Current | 2.1A |
| Operating Current | 40A |
| Operating Voltage | 59V |
| Operating Temperature | 25°C |
| Storage Temperature | -35~75°C |
| Wavelength Temperature Coefficient | 0.33nm/°C |
| Anti Reflection Wavelength Range | 1030~1200nm |
| Reflection Efficiency | 30dB |
| Soldering Temperature | 260°C(10sec) |
